DD

Spray Characteristics

  • Produces highly uniform flat spray at high pressures.
  • Maximum impinging force is produced with a minimum loss of energy resulting in higher efficiency.
  • Spray pattern has a knife-like cutting edge.
  • Normal spray angles of 25° and 32°.
  • Orifice is offset 15° to axis of dovetail.

Construction and Materials

  • Dovetail connection nozzle/body for positive alignment.
  • 3 piece design with Male BSPT thread or Welding Nipple body, available in:
  • Stainless Steel bodies and cap.
  • Mild Steel (Welding Nipple body only).
  • Longer welding nipple bodies available to special order.
  • Nozzle is 416 Hardened Stainless Steel.
  • Tips, bodies and cap can be ordered separately in different materials
  • Threaded bodies are 3/4" or 1" Male BSPT only.
  • Other materials available to special order.

Order Example

  • DD 20-32 Hardened Stainless Steel = Tip Only.
  • 3/4" DDM (Male) 40-25'b0 Stainless Steel = Complete Assembly.
  • DDW 60-32° Stainless Steel = Welding Assembly.

Maximum Recommended
Pressure: 275 Bar.G.}

Construction and Materials

  • Dovetail connection nozzle/body for positive alignment.
  • 3 piece design with Male BSPT thread or Welding Nipple body, available in:
  • Stainless Steel bodies and cap.
  • Mild Steel (Welding Nipple body only).
  • Longer welding nipple bodies available to special order.
  • Nozzle is 416 Hardened Stainless Steel.
  • Tips, bodies and cap can be ordered separately in different materials
  • Threaded bodies are 3/4" or 1" Male BSPT only.
  • Other materials available to special order.

Order Example

  • DD 20-32 Hardened Stainless Steel = Tip Only.
  • 3/4" DDM (Male) 40-25'b0 Stainless Steel = Complete Assembly.
  • DDW 60-32° Stainless Steel = Welding Assembly.

Maximum Recommended
Pressure: 275 Bar.G.}

Construction and Materials

  • Dovetail connection nozzle/body for positive alignment.
  • 3 piece design with Male BSPT thread or Welding Nipple body, available in:
  • Stainless Steel bodies and cap.
  • Mild Steel (Welding Nipple body only).
  • Longer welding nipple bodies available to special order.
  • Nozzle is 416 Hardened Stainless Steel.
  • Tips, bodies and cap can be ordered separately in different materials
  • Threaded bodies are 3/4" or 1" Male BSPT only.
  • Other materials available to special order.

Order Example

  • DD 20-32 Hardened Stainless Steel = Tip Only.
  • 3/4" DDM (Male) 40-25'b0 Stainless Steel = Complete Assembly.
  • DDW 60-32° Stainless Steel = Welding Assembly.

Maximum Recommended
Pressure: 275 Bar.G.}
